CMD130 Truck-Mounted Large-Diameter Drilling Rig
Rapid-Response Power for Emergency Rescue and Multi-Well Campaigns
The CMD130 truck-mounted large-diameter drilling rig is engineered for speed-critical missions: emergency mine rescue, rapid-response geothermal, and multi-well coalbed methane programs. Mounted on a highway-legal 6×6 chassis, it travels at 80 km/h and drills within hours of arrival—no cranes, no flatbeds, no delays.
Deploy in Hours, Not Days
Self-propelled with integrated winch and hydraulic stabilizers
Telescopic mast raises in under 30 minutes
Automated rod handler reduces crew size and manual handling risks
Total setup time: <2 hours on prepared pads
Rescue-Grade Large-Diameter Performance
As a true large-diameter drilling rig, the CMD130 drills full 914 mm (36") boreholes without pilot holes—critical for life-saving airways and evacuation shafts. Key specs:
130-ton hoist capacity
Drills rescue boreholes to 800+ meters
Real-time downhole telemetry for dynamic decision-making
Redundant hydraulic circuits ensure operation during emergencies
Field-Proven in Life-or-Death Scenarios
Deployed by national mine rescue teams in China and South Africa, the CMD130 established a 600-meter rescue borehole in just 36 hours during a 2023 entrapment incident. For CBM contractors, it enables “drill-and-move” efficiency across clustered well pads—completing 10+ wells per month.
Technical & Compliance Highlights
Cummins X15 engine (600 HP) with DEF aftertreatment (Tier 4 Final)
GPS tracking and remote diagnostics via secure cloud platform
Elevated drill floor (2.1 m) supports BOP installation for safe CBM operations
CE-certified safety cage, emergency shutdown, and satellite comms
Transport dimensions: 14.8 m × 2.98 m × 4.3 m (~60 tons)—compliant with EU/China over-dimensional regulations with escort
Certified to ISO 9001 and aligned with MSHA-equivalent safety protocols, the CMD130 includes an emergency oxygen delivery system for underground communication boreholes.
Versatile Applications
Mine rescue: communication, air supply, and evacuation boreholes
Coalbed methane: fast-turnaround appraisal and production wells
Disaster response: landslide dewatering and slope stabilization
Geothermal: temporary test wells in remote basins
For operators seeking a truck-mounted large-diameter drilling rig that’s ready to drill on arrival, the CMD130 delivers unmatched readiness without compromising power or safety.
When every minute counts, choose the rig that arrives ready to drill.
→ Get a deployment timeline estimate, technical datasheet, or request a demo unit today.
CMD130 – Key Technical Specifications
|
System |
Parameter |
Value |
|
Feed System |
Hoisting Capacity |
130 t |
|
|
Downward Thrust |
26 t |
|
Rotary Table |
Maximum Opening Diameter |
820 mm |
|
|
Maximum Working Table Height |
2.08 m (Note: corrected from “2.08 mm”) |
|
|
Hydraulic Pipe Gripper |
Yes (Hydraulically Actuated) |
|
Kelly Drive (Power Head) |
Maximum Torque |
31,000 N·m |
|
|
Maximum Rotational Speed |
300 rpm |
|
|
Through-Hole Diameter |
115 mm |
|
Mast |
Mast Length (Fully Extended) |
21.2 m |
|
|
Mast Length (Fully Retracted) |
13.6 m |
|
|
Power Head Stroke |
15.2 m |
|
|
Number of Stabilizing Outriggers |
6 |
|
Overall Dimensions & Weight |
Machine Dimensions (L × W × H) |
14.8 m × 2.77 m × 4.3 m |
|
|
Total Operating Weight |
60 t |
|
|
Road-Registered Weight (for transport) |
54.5 t |
|
Power System |
Main Engine (Drilling) |
Chongqing Cummins QSK19-C760 |
|
|
Rated Power (Drilling Engine) |
567 kW @ 2100 rpm |
|
Carrier Chassis |
Drive Configuration |
10×8 |
|
|
Chassis Engine Power |
338 kW @ 1900 rpm |
|
Winch |
Lifting Capacity |
3.5 t |
|
Air/Mud Circulation System |
Maximum Pressure Rating |
35 MPa |
|
|
Air Compressor |
External (Auxiliary) |
|
|
Mud Pump |
External (Auxiliary) |
|
|
Pipeline Internal Diameter |
76 mm |
